Geomagic Design X

Geomagic Design X, the industry's most comprehensive reverse engineering software, combines history-based CAD with 3D scan data processing so you can create feature-based, editable solid models compatible with your existing CAD software. And now Design X offers three software plans to meet any need and any budget.

Dx Go
Dx Go allows you to start reverse engineering parts with easy-to-use software.

DxPlus
Dx Plus delivers an enhanced toolset that integrates directly with your 3D scanner.

DxPro
Dx Pro offers the robust tool set you need to turn your 3D scan to CAD better and faster than anything on the market.

Powerful and Flexible

Geomagic Design X is purpose-built for converting 3D scan data into high-quality feature-based CAD models. It does what no other software can with its combination of automatic and guided solid model extraction, incredibly accurate exact surface fitting to organic 3D scans, mesh editing and point cloud processing. Now, you can scan virtually anything and create manufacturing-ready designs.

Enhance Your CAD Environment

Seamlessly add 3D scanning into your regular design process so you can do more and work faster. Geomagic Design X complements your entire design ecosystem, with native output to SOLIDWORKS®, Siemens NX®, Solid Edge, Autodesk Inventor®, PTC Creo® and Pro/ENGINEER® using the patented LiveTransfer technology. This enables very rapid transition of your scanned model into the mainstream CAD environment that you use.

Accelerate Time to Market

Shave days or weeks from product idea to finished design. Scan prototypes, existing parts, tooling or related objects, and create designs in a fraction of the time it would take to manually measure and create CAD models from scratch.

Do the Impossible

Create products that cannot be designed without reverse engineering, customized parts that require a perfect fit with the human body. Create components that integrate perfectly with existing products. Recreate complex geometry that cannot be measured any other way.

VideosFeaturesBenefitsImagesData Sheets
  • Supports all 3D Scanners
  • Point cloud editing and fast creation of accurate polygonal models based on the 3D scan data
  • Powerful Remesh tool for fast, accurate create clean polygon models from dirty scan data
  • Polygon editing tools for hole filling, smoothing, patching and water tight model creation
  • Immediately use the data from Geomagic Wrap for 3D printing, rapid prototyping, and manufacturing.
  • Extensive Exact Surfacing tools give more control over your surface quality and layout, and allows for total control over NURBS patch layout, surface quality, and continuity.
  • Create 3D Solid Models from Scan data
  • Export neutral (IGES, STEP, ParaSolid) or native (Creo, SolidWorks, AutoCAD, Inventor, Siemens NX) files using the the "Live Transfer" feature
  • Industry standard software
  • Easy to use
  • Work with any 3D Scanning technology
  • Import, Edit, create and render in all one software package
  • The only scanning software able to generate feature based solid models from scan data
    • 3D Scan data to solid CAD model
    3D Scan data to solid CAD model
    Compare scan data to CAD data
    Create complex CAD models from 3D scan data
    Compare scan data to CAD data
    3D Scan data to solid CAD model
    Work with large data sets
    3D Scan data to solid CAD model
    geomagic-design-x-engine-cad
    History tree CAD models from scan data
    3D Scan data to solid CAD model
    3D Scan data to solid CAD model
    3D Scan data to solid CAD model
